YH1.5W-2.4/6 and 3 variants · ≤10kV
Composite Housing Metal Oxide Surge Arrester for Motor Neutral Point
Composite Housing Metal Oxide Surge Arrester for Motor Neutral Point, YH1.5W-2.4/6 and 3 variants, for ≤10kV systems. Product identity and ratings follow the customer-supplied electrical catalog.
- Model series
- YH1.5W-2.4/6 and 3 variants
- System voltage
- ≤10kV
- Installation
- Outdoor / motor neutral point
- Operating temperature
- -40℃~+40℃
Product Overview
Catalog-matched product identity
Composite Housing Metal Oxide Surge Arrester for Motor Neutral Point, YH1.5W-2.4/6 and 3 variants, for ≤10kV systems. Product identity and ratings follow the customer-supplied electrical catalog.
Technical Data
Customer catalog values
Product lineComposite Housing Metal Oxide Surge Arrester for Motor Neutral Point
Model seriesYH1.5W-2.4/6 and 3 variants
System voltage≤10kV
Continuous operating voltage1.9~3.8 kV
Nominal discharge current1.5 kA
Protection level6~12 kV
InstallationOutdoor / motor neutral point
Operating temperature-40℃~+40℃
ApplicationOvervoltage protection for rotating-machine neutral points
Included modelsYH1.5W-2.4/6, YH1.5W-4.8/12, YH1.5W-8/19 (3 variants total)
Names, models and ratings are transcribed from the customer-supplied catalog. Final configuration follows the approved model and project schedule.
Applications
Application scope
Overvoltage protection for rotating-machine neutral points
