YH5WS-10/30x10/30 and 32 variants · ≤10kV
Composite Housing Metal Oxide Surge Arrester for Distribution
Composite Housing Metal Oxide Surge Arrester for Distribution, YH5WS-10/30x10/30 and 32 variants, for ≤10kV systems. Product identity and ratings follow the customer-supplied electrical catalog.
- Model series
- YH5WS-10/30x10/30 and 32 variants
- System voltage
- ≤10kV
- Installation
- Standard D48 installation
- Operating temperature
- -40℃~+45℃
Product Overview
Catalog-matched product identity
Composite Housing Metal Oxide Surge Arrester for Distribution, YH5WS-10/30x10/30 and 32 variants, for ≤10kV systems. Product identity and ratings follow the customer-supplied electrical catalog.
Technical Data
Customer catalog values
Product lineComposite Housing Metal Oxide Surge Arrester for Distribution
Model seriesYH5WS-10/30x10/30 and 32 variants
System voltage≤10kV
Continuous operating voltage2~13.6 kV
Nominal discharge current5 kA
Protection level15~50 kV
InstallationStandard D48 installation
Operating temperature-40℃~+45℃
ApplicationOvervoltage protection for 10 kV cable outgoing equipment
Included modelsYH5WS-10/30x10/30, YH5WS-17/50x17/50, YH5WS-5/15x5/15, YH5WS-12.7/50Q, YH5WS-17/50Q, YH5WS-10/30, YH5WS-12.7/50, YH5WS-17/50, YH5WS-3.8/15, YH5WS-5/15, YH5WS-7.6/30, HY5WS-10/30DL, HY5WS-17/50DL, HY5WS-10/30DL-TB, HY5WS-17/50DL-TB, YH10WS-17/50, YH10WS-17/50TL, YH5WS-17/50DL, YH5WS-17/50TL, YH10WS-17/45, YH10WS-17/45DL-TR, YH10WS-17/45DL-TR (Fujian configuration), YH10WS-17/45Q, YH10WS-17/45TL, YH10WS-17/45TLQ, YH5WS-17/45, YH5WS-17/45DL-TR, YH5WS-17/45Q, YH5WS-17/45TL, YH5WS-17/45TLQ, YH5WS-17/50DZ (M10, with disconnector), YH5WS-17/50DZ (M16, without disconnector) (32 variants total)
Names, models and ratings are transcribed from the customer-supplied catalog. Final configuration follows the approved model and project schedule.
Applications
Application scope
Overvoltage protection for 10 kV cable outgoing equipment
