RW10-35/0.5 and 26 variants · 35kV
Outdoor High-voltage Current-limiting Fuse
Outdoor High-voltage Current-limiting Fuse, RW10-35/0.5 and 26 variants, for 35kV systems. Product identity and ratings follow the customer-supplied electrical catalog.
- Model series
- RW10-35/0.5 and 26 variants
- System voltage
- 35kV
- Installation
- Outdoor / overhead line
- Operating temperature
- -40℃~+45℃
Product Overview
Catalog-matched product identity
Outdoor High-voltage Current-limiting Fuse, RW10-35/0.5 and 26 variants, for 35kV systems. Product identity and ratings follow the customer-supplied electrical catalog.
Technical Data
Customer catalog values
Product lineOutdoor High-voltage Current-limiting Fuse
Model seriesRW10-35/0.5 and 26 variants
System voltage35kV
InstallationOutdoor / overhead line
Operating temperature-40℃~+45℃
ApplicationShort-circuit and overload protection for transmission lines, power transformers and voltage transformers
Included modelsRW10-35/0.5, RW10-35/2, RW10-35/3~10, RW9-35/0.5, RW9-35/2, RW9-35/3~10, RWX0-35/0.5, RWX0-35/2, RWX0-35/3, HRW10-12/200, HRW11-12/200, HRW12-12/200, HRW5-40.5/200, RW10-12/200, RW11-12/200, RW12-12/200, RW5-40.5/200, HPRWG2-40.5/200, PRWG2-40.5/200, HRW10-12F/200, RW10-12F/200, FZRWG5-35/200A, NRW-12/200, FZRWG5-40.5/200, RW10-40.5/0.5A, RXWO-40.5/0.5A (26 variants total)
Names, models and ratings are transcribed from the customer-supplied catalog. Final configuration follows the approved model and project schedule.
Applications
Application scope
Short-circuit and overload protection for transmission lines, power transformers and voltage transformers
