Light-Duty PVC Sheathed Cable
Light-Duty PVC Sheathed Cable covers the 60227 IEC 10(BVV), ZA(B/C)-60227 IEC 10(BVV) model series in the PVC Insulated Wire and Cable range, with 300/500V rating, 3~5 cores and 1.5~35mm².
- Model series
- 60227 IEC 10(BVV), ZA(B/C)-60227 IEC 10(BVV)
- Rated voltage
- 300/500V
- Core configuration
- 3~5 cores
- Standard
- GB/T5023.4(IEC 60227-4) / GB/T19666
Product Overview
Catalog-matched product identity
Light-Duty PVC Sheathed Cable covers the 60227 IEC 10(BVV), ZA(B/C)-60227 IEC 10(BVV) model series in the PVC Insulated Wire and Cable range, with 300/500V rating, 3~5 cores and 1.5~35mm².
Technical Data
Customer catalog values
Product categoryPVC Insulated Wire and Cable
Model series60227 IEC 10(BVV), ZA(B/C)-60227 IEC 10(BVV)
Rated voltage300/500V
Core configuration3~5 cores
Conductor cross-section1.5~35mm²
InsulationPolyvinyl chloride (PVC)
SheathPolyvinyl chloride (PVC)
Operating temperature70°C
Fire performanceZA / ZB / ZC flame-retardant classes A / B / C (non-flame-retardant type also available)
StandardGB/T5023.4(IEC 60227-4) / GB/T19666
Names, models and ratings are transcribed from the customer-supplied catalog. Final configuration follows the approved model and project schedule.
Applications
Application scope
PVC Insulated Wire and Cable300/500V systemsProject-specific electrical installations
